SmoothBaler3 conveyor belt material fabricated by Shipp Belting Company. The belt compound is Rubber with a smooth top surface and friction skim bottom surface.
SmoothBaler3
Contact Us Directly for Immediate Assistance
Belt Specifications *
| Belt Compound | |
|---|---|
| Top Surface | Smooth |
| Bottom Surface | Friction Skim |
| Color | Black |
| Number of Plies | 3 |
| Nominal Thickness (in) | 0.25 |
| Anti-Static | No |
| Max. Width | 60 |
| Working Tension | 330 |
| Weight (Lbs) | 0.125 |
| Min. Pulley Diameter (in) | 4 |
| Min. Temperature | -25 |
| Max. Temperature | 225 |
| Clipper | 4-1/2RHTX |
| Staple | ARJ |
| Fabric | Polyester |
| Meets FDA Requirements | No |
| USDA Official Approval | No |
